New for 2024:
A more efficient intake path and revised ECU settings results in even more mid- to high-end power.
Exclusive Power Tuner App
The free of charge and industry-exclusive Yamaha Power Tuner app brings the power of the GYTR Power Tuner to your iOS® or Android® device. Using wireless connectivity to talk to the bike’s onboard CAN-bus network, the app allows owners to adjust air/fuel mixture and ignition timing maps to tune engine performance for track conditions, record race log information and monitor a range of data such as maintenance and system diagnosis, engine run time and more.
Adjustable Engine Maps
Two-mode adjustable engine mapping allows the rider to adjust engine character with the push of a button, making it easy to tune the YZ250F for changing track or weather conditions.
Electric Starter System
The YZ250F features a compact electric starter system that minimizes restart delays on track and adds convenience everywhere else. Powered by a high-capacity and ultra-lightweight, four-cell lithium-ion battery, the system adds minimal weight.
Piston, Rod and Crankshaft Balance
A flat-top forged piston features a bridge-box design for additional strength with minimal weight. The piston, rings and DLC-coated piston pin, along with the offset cylinder configuration, all reduce friction loss and contribute to quick response. The engine’s intake ports, cam profiles, high-strength connecting rod and optimized crank and counterbalancer all work together to produce potent high-rpm power with user-friendly delivery and exceptional reliability.
Advanced Fuel Injection
The adjustable fuel injection system uses a 44 mm throttle body, fed by a high-pressure electric fuel pump that injects fuel through a 12-hole Denso® injector. This ensures optimum fuel atomization and air/fuel calibration for excellent rideability in a wide range of riding conditions.
Wraparound Rear-Positioned Exhaust Layout
An innovative exhaust pipe design improves mass centralization and power development characteristics. This layout moves the rear end of the exhaust pipe farther forward and positions the muffler closer to the bike’s center of mass.
Durable Transmission
The transmission gears, dogs and shift mechanisms are designed to smooth gear changes and improve durability under the heavy demands of motocross racing. The YZ250F also features a large-diameter clutch to boost reliability even further under high-heat conditions.
All-New Aluminum Bilateral Beam Frame
A completely redesigned aluminum bilateral beam frame based on the flagship YZ450F provides just the right amount of strength and flex for the perfect balance of straight-line stability and cornering performance. The result is a better handling machine with lighter feel, more agility and increased traction, allowing the rider to charge corners with greater confidence.
Slimmer Body & Improved Ergos
The new 2024 YZ250F has a slimmer, flatter body design for improved control, including a more narrow fuel tank, lower airbox and more narrow radiator shrouds. The rider triangle is also improved with increased legroom between the seat and footpegs for greater rider comfort.
Revised Suspension Settings
Class leading, fully adjustable KYB® coil spring-type fork with speed-sensitive damping delivers exceptional balance between handling and bump absorption for championship-winning performance. New for 2024, the fork now includes hand-adjustable knob for toolless compression adjustment. Linkage-type rear suspension features a KYB® shock with revised settings to provide less pitch on corner entry/exit for improved stability.
Enhanced Mass-Centralization
The engine, aluminum muffler and compact fuel tank are positioned close to the machine's centre of mass. This layout contributes to centralized mass for a lightweight handling feeling on the track. The wide 55 mm foot pegs help lower the rider's centre of gravity for enhanced machine balance, control and rider comfort.
270 mm Front Brake
A large 270 mm front brake disc is the same system fitted to the YZ450F and uses an aggressive pad material for exceptional stopping power and braking control. Out back, a durable heat-resistant rear rotor boosts brake durability.
Strong, Lightweight Wheels
Careful computer-aided refinement of each wheel’s cross-sectional profile shaves valuable weight without sacrificing durability.
